Nidec D14P2B4

Nidec · General Purpose Three Phase ODP NEMA Premium Efficient – IE3
1/4 HP 1725 48 Fr ODP 208-230V|460V General Purpose
Catalog Number: D14P2B4
Model Number: P055DHS1586015B
HP
1/4
RPM
1800
Voltage
208-230V, 460V
Frame
48
Phase
3
Enclosure
ODP
Material
Rolled Steel
Mounting
Rigid

NO STOCKING INFORMATION AVAILABLE

See from other brands that have matching specifications to this product.

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Description

For pumps, fans, compressors, material handling, and other general purpose applications where contaminants are minimal.

Description

  • Class F Insulation
  • 40°C Ambient, NEMA®† Design B Performance On 60 Hz Sine Wave Power
  • 15 Service Factor
  • Regreasable Bearings 180 Frame & Up
  • Double Shielded Bearings 140-400, Open on 440
  • Lifting Provisions 180 Frame & Up
Electrical Data
Rated Motor Output Power
1/4 HP
.19 kW
Rated Motor Speed
1725 RPM
Rated Motor Voltage
208-230V,460V
Rated Motor Current
1.3-1.3/.7 AMP
Phase
3
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
1.3
Service Factor
1.35
KVA Code
N
Nominal Efficiency
69.5
Nominal Power Factor
-
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
48
Enclosure
ODP
Mounting
Rigid
Number of Speeds
1 Speed
Approximate Weight
-
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
9.6"
NEMA Design
B
Degree of Protection (IP)
-
Insulation Class
B
Rotation
Reversible
Duty
-
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.5"
Shaft Length
1.5"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA, UL & CE
Country of Origin
-
Warranty
1-Year
