Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson C1909

Leeson
1 1/2HP 1725 56 TENV 115V|230V Farm Duty
Catalog Number: C1909
Part Number: 5KCR49ZN0785S
HP
1 1/2
RPM
1800
Voltage
115V,208-230V
Frame
56
Phase
1
Enclosure
TENV
Material
Rolled Steel
Mounting
Resilient

Ships next business day

Available for Delivery

To get accurate delivery estimates, please enter your postal code.

Stock Locations

Mississauga, ON: In Stock
Edmonton, AB: Out of Stock
Factory Ordered: 3-5 weeks

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No cross-referenced matches have been found, but our team may be able to help find an alternate solution.

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Capacitor start/capacitor run design for reduced amperage
  • 48Z Frame has 1/2” dia. x 2-1/2” long shaft with two flats
  • 56Z Frame has 1/2” dia. x 1-7/8” long with 1-5/8” flat
  • 48Y & 48YZ have 48/56 Fr. Mounting holes
  • Designed for 50 Hz operation
  • Fully Gasketed
  • Shaft ext 3-13/16" L by 5/8" dia., 3.5" keyway
Electrical Data
Rated Motor Output Power
1 1/2 HP
1.125 kW
Rated Motor Speed
1725 RPM
Rated Motor Voltage
115V,208-230V
Rated Motor Current
14.0/7.0 AMP
Phase
1
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
7.2
Service Factor
1.3
KVA Code
K
Nominal Efficiency
78.5
Nominal Power Factor
-
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56
Enclosure
TENV
Mounting
Resilient
Number of Speeds
-
Approximate Weight
49lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
21.02"
NEMA Design
-
Degree of Protection (IP)
-
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
1.875"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & UL
Country of Origin
-
Warranty
1-Year
