Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson F101

Leeson
1/3HP 1725 56 TEFC 115V|230V Farm Duty
Catalog Number: F101
Part Number: 056C17F5324
HP
1/3
RPM
1800
Voltage
115V,208-230V
Frame
56
Phase
1
Enclosure
TEFC
Material
Rolled Steel
Mounting
Rigid

Ships next business day

Available for Delivery

To get accurate delivery estimates, please enter your postal code.

Stock Locations

Edmonton [eMotors #2], AB: In Stock (1)
Edmonton, AB: Out of Stock
Factory Ordered: 3-5 weeks
Mississauga, ON: Out of Stock

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Shaft end mechanically locked on C-face models
  • Ball bearings
  • 1.15 service factor (except as noted)
  • Low temperature manual reset thermal protector
  • Totally enclosed and fully gasketed construction for dirty environments
  • Condensate drains
  • Shaft slinger
  • UL recognized and CSA certified
Electrical Data
Rated Motor Output Power
1/3 HP
.24 kW
Rated Motor Speed
1725 RPM
Rated Motor Voltage
115V,208-230V
Rated Motor Current
6.6/3.1 AMP
Phase
1
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
3.3
Service Factor
1.15
KVA Code
N
Nominal Efficiency
55
Nominal Power Factor
60
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56
Enclosure
TEFC
Mounting
Rigid
Number of Speeds
-
Approximate Weight
24lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
26.66"
NEMA Design
L
Degree of Protection (IP)
IP43
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
60°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
2.32"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & UL
Country of Origin
-
Warranty
1-Year
