Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson F105

Leeson
1 1/2 HP 1725 56H TEFC 115V|208-230V Farm Duty
Catalog Number: F105
Part Number: 056B17F5307
HP
1 1/2
RPM
1800
Voltage
115V,208-230V
Frame
56H
Phase
1
Enclosure
TEFC
Material
Rolled Steel
Mounting
Rigid

Ships next business day

Available for Delivery

To get accurate delivery estimates, please enter your postal code.

Stock Locations

Edmonton, AB: In Stock
Mississauga, ON: Out of Stock
Factory Ordered: 3-5 weeks
Edmonton [eMotors #2], AB: In Stock (2)

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Shaft end mechanically locked on C-face models
  • Ball bearings
  • 1.15 service factor (except as noted)
  • Low temperature manual reset thermal protector
  • Totally enclosed and fully gasketed construction for dirty environments
  • Condensate drains
  • Shaft slinger
  • UL recognized and CSA certified
Electrical Data
Rated Motor Output Power
1 1/2 HP
1.125 kW
Rated Motor Speed
1725 RPM
Rated Motor Voltage
115V,208-230V
Rated Motor Current
15.2/7.6 AMP
Phase
1
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
8.2
Service Factor
1.15
KVA Code
J
Nominal Efficiency
80
Nominal Power Factor
80
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56H
Enclosure
TEFC
Mounting
Rigid
Number of Speeds
-
Approximate Weight
41lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
13.82"
NEMA Design
L
Degree of Protection (IP)
IP43
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
2.25"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & UL
Country of Origin
-
Warranty
1-Year
