Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson G396

Leeson
1 1/2 HP 1800 56HC TEFC 115V|208-230V General Purpose
Catalog Number: G396
Part Number: 056B17F5310
HP
1 1/2
RPM
1800
Voltage
115V,208-230V
Frame
56HC
Phase
1
Enclosure
TEFC
Material
Rolled Steel
Mounting
C-Face / Rigid

Availability: Factory Order

Need it Now?

See our for equivalent alternatives

Stock Locations

This item is factory ordered. Shipping time may vary. Contact our team for an accurate shipping estimate.

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Ball bearings, shaft end mechanically locked on C-face models
  • Heavy gauge steel constructions
  • Continuous duty, 1.15 service factor
  • Manual reset thermal protector
  • UL recognized and CSA certified
Electrical Data
Rated Motor Output Power
1 1/2 HP
1.125 kW
Rated Motor Speed
1800 RPM
Rated Motor Voltage
115V,208-230V
Rated Motor Current
13.6/7.5-6.8 AMP
Phase
1
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
7.5
Service Factor
1.15
KVA Code
K
Nominal Efficiency
81.5
Nominal Power Factor
87
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56HC
Enclosure
TEFC
Mounting
C-Face / Rigid
Number of Speeds
-
Approximate Weight
43lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
13.82"
NEMA Design
-
Degree of Protection (IP)
IP43
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
1.875"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & CE
Country of Origin
-
Warranty
1-Year
