Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson K615

Leeson
2 HP 3600 56HC TEFC 115V|230V General Purpose
Catalog Number: K615
Part Number: 056B34F5312
HP
2
RPM
3600
Voltage
115V,230V
Frame
56HC
Phase
1
Enclosure
TEFC
Material
Rolled Steel
Mounting
C-Face / Rigid

Availability: Factory Order (3-5 weeks)

Available for Delivery

To get accurate delivery estimates, please enter your postal code.

Stock Locations

Edmonton, AB: Out of Stock
Mississauga, ON: Out of Stock
Factory Ordered: 3-5 weeks

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Cross-Referenced Matches (1)

Equivalent alternatives from other brands that have matching specifications to this product.

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Ball bearings, shaft end mechanically locked on C-face models
  • Heavy gauge steel constructions
  • Continuous duty, 1.15 service factor
  • Manual reset thermal protector
  • UL recognized and CSA certified
Electrical Data
Rated Motor Output Power
2 HP
1.5 kW
Rated Motor Speed
3600 RPM
Rated Motor Voltage
115V,230V
Rated Motor Current
17.5/8.7 AMP
Phase
1
Poles
2
Locked Rotor Current
-
Fl Current @ 208V
-
Service Factor
1.15
KVA Code
J
Nominal Efficiency
80.5
Nominal Power Factor
92.2
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56HC
Enclosure
TEFC
Mounting
C-Face / Rigid
Number of Speeds
-
Approximate Weight
37lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
13.32"
NEMA Design
-
Degree of Protection (IP)
IP43
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
1.875"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA
Country of Origin
-
Warranty
1-Year
