Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson U422A

Leeson
2 HP 1750 145T ODP 200-208V General Purpose
Catalog Number: U422A
Part Number: 145TTDR16056
HP
2
RPM
1800
Voltage
200-208V
Frame
145T
Phase
3
Enclosure
ODP
Material
Rolled Steel
Mounting
Rigid

Availability: Factory Order

Stock Locations

This item is factory ordered. Shipping time may vary. Contact our team for an accurate shipping estimate.

Important Links

Need it Now?

See our for equivalent alternatives

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Meets or exceeds all USA mandated efficiencies
  • UL recognized, CSA certified and CE mark
  • Motors are suitable for 10:1 VT
Electrical Data
Rated Motor Output Power
2 HP
1.5 kW
Rated Motor Speed
1750 RPM
Rated Motor Voltage
200-208V
Rated Motor Current
6.6-6.6 AMP
Phase
3
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
6.6
Service Factor
1.15
KVA Code
N
Nominal Efficiency
86.5
Nominal Power Factor
74.5
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
145T
Enclosure
ODP
Mounting
Rigid
Number of Speeds
-
Approximate Weight
46lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
14.49"
NEMA Design
B
Degree of Protection (IP)
IP22
Insulation Class
F
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
203
NDE Bearing
203
Shaft Diameter
0.875"
Shaft Length
2.25"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA, UL & CE
Country of Origin
-
Warranty
3-Year
