KB Electronics KBWM-120

KB Electronics · KBWM - DC Drive
KBWM SCR Drive - NEMA 1 1/3 HP 90V (No.9380)
Catalog Number: KBWM-120
Part Number: 9380
HP
1/3
Input Voltage
115V
Output Voltage
90V
Input Phase
1
Enclosure
NEMA 1

Overview

Our selection of KB Electronics DC drives offers a wide variety of drives for DC motor variable speed control. Select a drive rated for fractional HP up to 5 HP rated motors and a large selection of input and output voltage ratings. They feature enclosures from chassis to NEMA 1 and NEMA 4X.

CAD$217.24

This product requires a resistor and fuse. Please include the HP and voltage of the motor that the drive will use with. This will be included with your drive.

Contact us for delivery dates

On Order

19 Expected12/15/2023
1 Expected12/18/2023

Need it Now?

See our for equivalent alternatives

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593
Returns & Refund Policy

Contact our team for alternative solutions

No cross-referenced matches have been found, but our team may be able to help find an alternate solution.

KB Electronics: KBWM - DC Drive (2)

KBWM-2403/4230V90V, 180V1NEMA 1 $217.24
KBWM-1201/3115V90V1NEMA 1 $217.24

Description

The KBWM Series of DC Drives are rated for 1/100 to 3/4 horsepower motors and are housed in a NEMA 1 enclosure. These drives are the compact version of the Multi Drive™ (KBMD). This unidirectional SCR drive utilizes the KBMM speed control module, which prevents motor failure due to demagnetization. It requires a Plug-in Horsepower Resistor to operate and includes an AC line fuse and an Armature fuse holder.

eMotors Direct’s stock of DC drives are for use with direct current power and DC motors. The simple design allows for motor speed control by adjusting the voltage of the supply power. They are ideal for situations where low speed, torque, and power are required. Cost-effective, user-friendly, and offering precise control, DC motor drivers are easy to implement on your industrial motor projects.

Our DC drive category covers the latest DC control technology, giving you a complete selection of single-phase and DC power input options. Horsepower options start at fractional HPs up to 7 ½ HP. Select the appropriate enclosure type for your application from chassis, NEMA 1, NEMA 4, NEMA 4/12, and NEMA 4x. Designed for various industries from agriculture to automation to fabrication and beyond, our offering of dc motor speed controllers is from the top brands, KB Electronics and Leeson.

Shop DC motor speed controllers online through our Canadian website today. With over 55 SKUs and convenient filtering options, you can easily find the DC drive you’re searching for.

Need a hand finding the right motor speed controller for your application or legacy replacement?  Contact our motor experts today. They have extensive knowledge, backed by over 45 years of experience, to help you with your electric motor project.

Electrical Data
HP CT Rating
1/3 HP
HP VT Rating
-
Input
Output
Voltage
115V
90V
Max CT Current
5
3.5
Max VT Current
-
-
Phase
1
DC
Hz Range
50-60
-
Physical Data
Weight
1 lb
Height
6.8"
Width
3.7"
Depth
2.9"
Enclosure
NEMA 1
Frame
-
Ambient Temp
45°C
Additional Data
Agency Approvals
cUL & CE
Country of Origin
USA
Warranty
18-Month

Customer Reviews

Reviews for this product are shared amongst other products of the same productline as they are the same product but vary by specifications (like HP or RPM).

5 stars
0
4 stars
0
3 stars
0
2 stars
0
1 star
0

There are no reviews for this product yet.

Be the first to write a review

About KB Electronics

After starting in New York in 1967, KB Electronics eventually moved their headquarters to a larger, more modern facility in Coral Springs, Florida. Now housed within the Nidec Corporation group of companies, they have access to a large distribution network made up of over 800 warehouses and facilities in over 30 countries.

KB Electronics leads the industry with ready-to-use, out-of-the-box custom drives, they manufacture and stock over 200 inventory items. Specializing in VFDs, KB takes pride in their consistent product quality and low lead times – superior product, delivered fast.
