Leeson X033

Leeson
1/2 HP 1075 48Y OAO 115V Furnace Motor
Catalog Number: X033
Part Number: 048A11O1674
HP
1/2
RPM
1200
Voltage
115V
Frame
48Y
Phase
1
Enclosure
OAO
Material
Rolled Steel
Mounting
Round Body

Availability: Factory Order (3-5 weeks)

Available for Delivery

To get accurate delivery estimates, please enter your postal code.

Stock Locations

Edmonton, AB: Out of Stock
Mississauga, ON: Out of Stock
Factory Ordered: 3-5 weeks

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Alternatives

This item has similar horsepower, RPM, voltage, frame size, phase, enclosure, and mounting and may be used as an alternative for the following motors:

BrandCatalog
EMERSON5460, K55MDA-4122
JS S88-931
MARATHON 48A11O1674, 48A1101674
RHEEM 51-23012-41
ROTOM R43600
SMITH FDL6001
UNIVERSAL U-685

Feature

  • Open frames and brackets (except X011 and X012) have enclosed shaft end bracket
  • Single and multi-speed models as noted
  • Grommeted lead exit
  • Weather resistant reversing plug
  • 2 1/2” adapter rings supplied, shipped loose in box
  • Extended thru-bolts on shaft end
  • 30” long leads
  • Automatic reset thermal protector
  • Ball bearings
  • UL recognized and CSA certified
  • Capacitor not included
Electrical Data
Rated Motor Output Power
1/2 HP
.37 kW
Rated Motor Speed
1075 RPM
Rated Motor Voltage
115V
Rated Motor Current
6.1 AMP
Phase
1
Poles
6
Locked Rotor Current
-
Fl Current @ 208V
-
Service Factor
1
KVA Code
A
Nominal Efficiency
64
Nominal Power Factor
90.9
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
5
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
48Y
Enclosure
OAO
Mounting
Round Body
Number of Speeds
1 Speed
Approximate Weight
15lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
10"
NEMA Design
-
Degree of Protection (IP)
IP10
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.5"
Shaft Length
5"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & UL
Country of Origin
-
Warranty
1-Year
