Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Marathon 174107.00

Marathon
1HP/2HP 90V/180V NEMA 4X REVERSING SCR CONTROL
Catalog Number: 174107.00
HP
1, 2
Input Voltage
115V, 230V
Output Voltage
90V, 180V
Input Phase
1
Enclosure
NEMA 4X
Ships in 3 to 5 business days

Available for Delivery

To get accurate delivery estimates, please enter your postal code.

Stock Locations

Edmonton [eMotors #2], AB: Out of Stock
Mississauga, ON: In Stock
Factory Ordered: 3-4 weeks

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Overview

These drives provide a reliable and economical solution for variable speed control of DC motors from 1/8 to 2 HP. Housed in a NEMA 4X enclosure, the dual voltage drive is ideal for washdown applications and provides protection from moisture, windblown dust and incidental contact.

Electrical Data
HP CT Rating
1,2 HP
HP VT Rating
2,3 HP
Input
Output
Voltage
115V,230V
180V,90V
Max CT Current
6.49
10
Max VT Current
-
-
Phase
1
DC
Hz Range
48-62
-
Physical Data
Weight
-
Height
7.5"
Width
5.63"
Depth
4.94"
Enclosure
NEMA 4X
Degree of Protection (IP)
-
Frame
-
Ambient Temp
10°C - 40°C
Additional Data
Agency Approvals
-
Country of Origin
-
Warranty
1-Year
