Baldor IR3510M

Baldor · Instant Reversing, Single Phase, TEFC, Foot Mounted
1 HP 1800 56 TEFC 230V Farm Duty
Catalog Number: IR3510M
HP
1
RPM
1800
Voltage
230V
Frame
56
Phase
1
Enclosure
TEFC
Material
Rolled Steel
Mounting
Rigid

Product-line overview

This line of Baldor instant reversing motors come in single phase and come in 1/3 horsepower up to 1 horsepower. They are specially built for barn cleaners, bulk feeders, mechanical gates/doors, and hoists. These high-starting torque motors are electrically designed for optimal performance in instant reversing applications.

Lubricated for life double shielded bearings limit contaminants from entering the motor, extending the life of your motor asset. This line also comes equipped with a gasketed manual reset thermal overload protection, giving you peace of mind that your motor is less likely to fail during peak season.

This line is built with a TEFC (totally enclosed fan cooled) enclosure. Due to the IP44 rating, this product is splash-proof and is considered safe for dry or sheltered areas where they will be minimally exposed to moisture.

Baldor motors are stocked in Edmonton, AB; Burlington, ON; and Saint-Hubert, QC. Most motors arrive within 1-5 business days when shipping to postal codes within Canada. Baldor motors are manufactured in Arkansas, USA.

CAD$763.78
Ships next business day

Available for Delivery

To get accurate delivery estimates, please enter your postal code.

Stock Locations

Edmonton [eMotors #2], AB: Out of Stock
Edmonton, AB: Out of Stock
Burlington, ON: Out of Stock
Saint-Hubert, QC: In Stock

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Features

  • Tan epoxy paint manual thermal overload with cover mounted in conduit box
  • Protects motor from harsh environments
  • Ball bearings, condensation drains, heavy-gauge steel construction

Common Applications

  • Barn cleaners
  • Bulk feeders
  • Industrial Applications

What is a Farm Duty Motor

Farm duty motors typically require a high starting torque and should be durable enough for harsh, outdoor environments. Often, farm duty motors come with a 1.15 service factor, allowing for short periods of overload. Because applications for ag motors are so diverse, manufacturers have developed specific motors for specific applications, such as auger drive motors or instant reverse motors.

Be sure to take note of the IP ratings for your motor, as this will determine what environment it’s intended for. For example, an IP44 motor can withstand water splashing on the motor and limits objects over 1mm from entering the motor. Verse an IP55 motor can withstand water projected from a low-pressure water jet and protects against dust.

These motors also typically come with sealed bearings to protect the motor from contaminants, which helps to extend the life of the motor.

Where to Buy Farm Duty Motors in Canada

eMotors Direct’s stock of farm duty electric motors are built tough for those harsh conditions of life on the farm. Operate your heavy machinery seasonally or around the clock, these workhorses can handle what you throw at them, with regular maintenance. Our farm duty motor category covers all the motors you need to keep your farm working, find electric auger duty motors, fan motors to dry your grain and cool your barn, and more.

Select a farm duty motor from the top brands you trust, like Baldor, Leeson, Century, Grain Guard, Nidec, Brook Crompton, and more. Meet your horsepower needs with options from fractional up to 100 HP. Choose a motor that works on either AC single-phase or three-phase power, or DC power if you don’t have access to the grid. Plus, keep your motor’s internals covered with different enclosure types; OAO, ODP, TEAO, TEFC, and TENV.

Shop farm duty electric motors online through our Canadian website today. With over 700 SKUs and convenient filtering options, you can easily find the motor you’re searching for.

Need a hand finding the right motor for your application or legacy replacement? Contact our motors experts. They have extensive knowledge, backed by over 45 years of experience, to help you with your electric motor project.

Electrical Data
Rated Motor Output Power
1 HP
Rated Motor Speed
1800 RPM
Rated Motor Voltage
230V
Rated Motor Current
6.2 AMP
Phase
1
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
-
Service Factor
1.15
KVA Code
K
Nominal Efficiency
65
Nominal Power Factor
70
Leads (Qty, Size)
8
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56
Enclosure
TEFC
Mounting
Rigid
Number of Speeds
-
Approximate Weight
40lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
13.25"
NEMA Design
L
Degree of Protection (IP)
-
Insulation Class
F
Rotation
Reversible
Duty
-
Conduit Box Location
-
Removable Feet
No
Orientation
-
Ambient Temp
-
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6205
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
1.875"
Grease Type
Polyrex EM
Greaseable
Yes
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA, UR
Country of Origin
USA
Warranty
2-Year

Customer Reviews

Reviews for this product are shared amongst other products of the same productline as they are the same product but vary by specifications (like HP or RPM).

5 stars
0
4 stars
0
3 stars
0
2 stars
0
1 star
0

There are no reviews for this product yet.

Be the first to write a review

About Baldor

Baldor is particularly well known for the Super-E motor, which is a premium efficient (IE3) motor. This flagship product offers increased efficiency and cost savings for manufacturing plants, compared to high efficiency (IE2) motors.

Baldor industrial motors perform in rugged applications with safety and durability in mind. Their popular products include AC motors, DC motors, farm duty motors, crusher duty motors, and explosion proof motors.

Formerly known as Baldor Electric Company, now the US Motor Business Unit of ABB, Baldor manufactures electrical motors under the Baldor-Reliance brand. Having been a member of the ABB group since 2011, Baldor Electric Company unified with ABB in March of 2018. After the rebrand, they are now known as ABB Motor and Mechanical (Canada) Inc, although new motor nameplates still indicate 'Baldor Reliance' in Canada.

Baldor Electric Motors work out of headquarters based in Fort Smith, Arkansas. Baldor Canada’s locations throughout the country provide applications, technical support, and distribution centres.
